Omarchy

An opinionated Arch + Hyprland Setup

Omarchy

Omarchy is DHH's Hyperland Arch config. I'm enjoying a lot more than Hyde already because it has (for me) less insane config and defaults.

This is a working list of the things I'm customizing after installing Omarchy.

Ctrl instead of Capslock

Capslock out of the box calls xcompose for emojis. I prefer to have it by a ctrl key for my dev/tmux/vim workflows.

nvim ~/.config/hyprland/input.conf

change the kb_options value:

kb_options = ctrl:nocaps

Claude, not ChatGPT

Open claude instead of chatgpt

nvim ~/.config/hyprland/bindings.conf

Change the ChatGPT bind to:

bindd = SUPER, A, Claude, exec, $webapp="https://claude.ai"

Zed (Code IDE)

curl -f https://zed.dev/install.sh | sh

Elixir

EDIT: You can now install with the menu: Super Alt Space > Install > Development > Elixir

mise list-all erlang

mise install erlang@[VERSION]

sh ~/.local/share/mise/installs/erlang/[VERSION]/activate

mise list-all elixir

mise install elixir@[VERSION]

mise use -g erlang@[VERSION]

mise use -g elixir@[VERSION]

Screensaver

Instead of the default Omarchy logo. To edit the logo: Super Alt Space > Style > Screen Saver

▄          ▄          ▄          ▄▄
██▄        ██▄        ██▄        ██
████▄      ████▄      ████▄      ██
██ ▀██▄    ██ ▀██▄    ██ ▀██▄    ██
██   ▀██▄  ██   ▀██▄  ██   ▀██▄  ██
██     ▀██▄██     ▀██▄██     ▀██▄██
██       ▀███       ▀███       ▀███
██         ▀█         ▀█         ▀█

Mouse Cursor speed

gsettings set org.gnome.desktop.peripherals.mouse speed 0.5

This is for Wayland, which Hyprland uses.

If you want to learn about photography, Marc Levoy's lectures are some of the best content I've seen. For the mildly experienced photographer (like myself) with an engineering background, his explanations fill in so many gaps with mathematics and physics.

Topics like:

• how do lenses work and what are the limitations?
• how does perspective and depth of field work?
• the history of photography
• and much more

He's a big deal in the field of digital photography, especially with HDR: https://en.wikipedia.org/wiki/Marc_Levoy

There are 18 lectures, and they're all excellent.

Youtube Playlist: https://www.youtube.com/watch?v=y7HrM-fk_Rc&list=PL7ddpXYvFXspUN0N-gObF1GXoCA-DA-7i

This post compares two camera lenses, one with auto focus and one manual focus:

• Sony FE 40mm F2.5G G Lens  (SEL40F25G) with autofocus
• Voigtlander 35mm f/2 Ultron VM manual focus lens (M mount)

The camera I used was Sony's A7Cii.

Why use a manual focus lens?

This is the big question I've been asking myself since Sony cameras are praised for their auto focus capabilities. Ultimately, it boiled down to wanting to try a different way of taking photos.

There are a number of drawbacks to shooting with the manual lens I chose:

• no access to auto focus, which includes auto tracking and a myriad of other features
• shutter priority mode (S) is not useful since the camera doesn't have the ability to auto-control the aperture of the lens.
• no meta information about the lens or focal length is saved in the image
• an M-mount to E-mount adapter is required
• and more

Despite the list of drawbacks, I've loved using a manual focus. The way it forces me to compose photos is really fun. Especially if you take photos where there are objects in the foreground (like through a fence), auto-focus can get in your way unless you know what you're doing.

The lens itself has really warm saturated colors. It's smaller in size (though equivalent in weight).

Comparison

I will compare the raw photos unedited except for cropping/rotating, and lens correction. In both cases, I've used a form of aperture priority (A) mode, where the shutter speed and ISO are automatically decided by the camera. This is how I shoot photos rather than manual to control everything to a precise setting.

My hypothesis going into this was that the final edited photos will look the same, but perhaps feel different. That distinction is subtle, but the approach to taking a photo with manual focus requires more focus and intention, which I've learned to enjoy.

Comparison: Takeaways

• the images are more blue on the Sony (cold), more orange on the Voigtlander (warm)
• vignetting is much more prominent with the Voigtlander lens
• colors more more saturated in the Voigtlander lens
• images with the Sony are more balanced, but also flat
• sharpness is about the same
• the Voigtlander feel more vintage without being edited

Comparison: Edited Photos

Comparing images with editing applied (coloring, lighting, etc) it really starts to come down to preference. The Voigtlander images definitely feel warmer, but that could be corrected in post if desired.

So, auto focus or Manual focus?

I think this really comes down to preference, but the main difference is experiential. It's hard to quantify in a side by side comparison.

In my opinion, the final product doesn't vary substantially. Personally I'm enjoying the Voigtlander MF lens, but maybe that's because it's something different and forces me to pay more attention to the process.

I take a lot of photos and I edit the ones I like in post. Lately I've been wondering how basic photo editing operations like contrast, saturation, exposure, etc. are actually work.

In this post I define image "saturation." Then I'll walk through some programming approaches how to adjust saturation with all the trade-offs.

Image Saturation

The saturation of an image is how vivid or intense the colors are.

Ways to edit image saturation

There are 2 main approaches to adjusting the saturation of an image.

All the code is on Github: https://github.com/nbw/foto/blob/main/src/cmds/saturation.rs

[1] HSV approach: slower but accurate

How it works:

Convert the image from RGB to its HSV (Hue, Saturation, Value) representation. Here's my blog post about what HSV is and how it works.

Once you have an image in HSV value of a pixel, adjust the S value appropriately, then convert back to an RGB pixel.

Pros:

• generally accurate way of adjusting saturation
• easy to rationalize
• preserves hue

Cons:

• compatibly CPU intensive to other approaches
• the conversion from RBG to HSV is a non-linear operation so you can't use things like SIMD to parallelize it at the CPU level

Rust code:

fn apply_hsv_saturation(img: DynamicImage, saturation: f32) -> Result<DynamicImage> {
    let mut out_img: RgbImage = ImageBuffer::new(img.width(), img.height());

    for (x, y, pixel) in img.to_rgb8().enumerate_pixels() {
        let [r, g, b] = pixel.0;
        let (h, s_base, v) = color::rgb_to_hsv(r, g, b);
        let s = (s_base * saturation).clamp(0.0, 1.0);

        let (r, g, b) = color::hsv_to_rgb(h, s, v);
        let new_pixel = image::Rgb([r, g, b]);
        out_img.put_pixel(x, y, new_pixel);
    }

    Ok(DynamicImage::ImageRgb8(out_img))
}

[2] Via Luminance approach: fast but has issues

How it works:

Luminance (L) and Saturation are related concepts; rather than HSV we can use HSL.

Conveniently, luminance can be approximated using the following equation (the ITU-R BT.601 standard, used to calculate the perceived brightness of a color):

L = 0.299 * R + 0.587 * G + 0.114 * B;

then we can calculate the new R', G', B' values using:

R' = L + (R - L) * saturation
G' = L + (G - L) * saturation
B' = L + (B - L) * saturation

Pros:

• fast and good enough for many cases
• linear operation that can be parallelized easily at the CPU level with tools like SIMD.

Cons

• With extreme adjustments can shift the hue in ways that are hard to control

Rust code using luminance approach:

fn apply_luminance_saturation(img: DynamicImage, saturation: f32) -> Result<DynamicImage> {
    let mut out_img: RgbImage = ImageBuffer::new(img.width(), img.height());

    for (x, y, pixel) in img.to_rgb8().enumerate_pixels() {
        let [r, g, b] = pixel.0;
        let r_f = r as f32;
        let g_f = g as f32;
        let b_f = b as f32;
        let luminance = 0.299 * r_f + 0.587 * g_f + 0.114 * b_f;

        let new_pixel = image::Rgb([
            (luminance + (r_f - luminance) * saturation) as u8,
            (luminance + (g_f - luminance) * saturation) as u8,
            (luminance + (b_f - luminance) * saturation) as u8,
        ]);
        out_img.put_pixel(x, y, new_pixel);
    }

    Ok(DynamicImage::ImageRgb8(out_img))
}

Rust code using luminance approach with Simd for performance:

fn apply_luminance_saturation_simd(img: DynamicImage, saturation: f32) -> Result<DynamicImage> {
    let mut out_img_raw = vec![0u8; img.to_rgb8().into_raw().len()];

    // NOTE:assumes Simd lane factor of 4,
    // but this value depends on your hardware!
    let lanes = 4;

    for (chunk_idx, rgb_chunk) in img
        .to_rgb32f()
        .into_raw()
        .chunks_exact(lanes * 3)
        .enumerate()
    {
        let chunk_start = chunk_idx * lanes * 3;
        let mut r_vals = [0f32; 4];
        let mut g_vals = [0f32; 4];
        let mut b_vals = [0f32; 4];

        for i in 0..lanes {
            r_vals[i] = rgb_chunk[i * 3] as f32;
            g_vals[i] = rgb_chunk[i * 3 + 1] as f32;
            b_vals[i] = rgb_chunk[i * 3 + 2] as f32;
        }

        let r_f = Simd::from_array(r_vals);
        let g_f = Simd::from_array(g_vals);
        let b_f = Simd::from_array(b_vals);

        let luminance =
            Simd::splat(0.299) * r_f + Simd::splat(0.587) * g_f + Simd::splat(0.114) * b_f;

        let sat: Simd<f32, 4> = Simd::splat(saturation);

        let r_out = luminance + (r_f - luminance) * sat;
        let g_out = luminance + (g_f - luminance) * sat;
        let b_out = luminance + (b_f - luminance) * sat;

        for i in 0..lanes {
            out_img_raw[chunk_start + i * 3] = (r_out[i].clamp(0.0, 1.0) * 255.0) as u8;
            out_img_raw[chunk_start + i * 3 + 1] = (g_out[i].clamp(0.0, 1.0) * 255.0) as u8;
            out_img_raw[chunk_start + i * 3 + 2] = (b_out[i].clamp(0.0, 1.0) * 255.0) as u8;
        }
    }

    let out_img = image::RgbImage::from_raw(img.width(), img.height(), out_img_raw)
        .expect("Failed to create image");

    Ok(image::DynamicImage::ImageRgb8(out_img))
}

Comparison of approaches:

Applying a saturation factor of 2.5 with each approach:

HSV

Luminance

Luminance with SIMD

Performance using a 3mb image wise we get:

. ./benchmarks/saturation                             rs    12:27

hsv     1.71s user 0.12s system 107% cpu 1.704 total

lum     1.02s user 0.11s system 112% cpu 1.010 total

lumsimd 1.11s user 0.15s system 111% cpu 1.121 total

The luminance simd approach is actually slower than without in this instance 🤔 so it would be worth spending time to make some optimizations there. For video processing video files, using SIMD should be a 3-10x speed increase.

I verified the same results on a 25mb image as well.

Conclusion

There are a bunch of way to edit an image's saturation. Each has it's tradeoffs or side-effects.

In the case of editing photos, the photographer's eye is the final judge; it's probably not super important which technique you use if you're adjusting saturation within reasonable limits. In that case, I'd probably opt for whatever is fastest.

Personally, I find saturation to be less useful compared to vibrance, which I'll look at in another post!

This post is about what the HSV (Hue, Saturation, Value) representation of an image is.

If I told you to visualize the color (125, 75, 200), what color do you see? 🤔

🧍When describing a color, as a human of course, you might say things like: “deep red” or “pastel purple” or “bright and muted orange."

🤖 Whereas a computer (and hardware) would say something like: RED: 125, GREEN: 75, BLUE:  200.

What is intuitive for us is different than what is logical for hardware. So in the 1970’s the Hue Saturation Value system (HSL, too) was invented to represent RGB color values in terms more intuitive to humans.

• Hue (H): the color (red, purple, green, ..). It’s a spectrum represented in degrees (red: 0°, green: 120°, blue 240°).
• Saturation (S): the intensity of the color. When describing a colors, it’s often the adjective.
• Value (V): the brightness.
  • Imagine that you were mixing paint 🎨 to make a color, the “value” would be how much white or black you mixed in (to brighten or darken it).

Consider the following...

• “Light sky blue”: light (V), sky (S), blue (H)
• “Muted deep red”: muted (V), deep (S), red (H)]

A HSV cone is a common way to visualize it:

Converting from RBG to HSV

Let's look at the RBG to HSV equations and try to understand what they're describing. They look complicated at first glance:

(equations reference)

Starting with the easiest:

VALUE: V = Cmax, is the most dominant color, i.e: the highest value (R, G, or B) of an RGB pixel. So if R = 200, and G and B are 100, then V is 200.

SATURATION: S = (Cmax - Cmin)/ Cmax, is the ratio between the highest and lowest RGB value divided by Cmax to normalize the value between 0 to 1. The exception if the pixel is black, in which case we assume 0 saturation.

HUE: H, returns an angle value between 0 to 360.

• If the brightest of the RGB values is Red, we expect the angle to be between 0° to 120°
• If the brightest of the RGB values is Green, we expect the angle to be between 120° to 240°
• If the brightest of the RGB values is Blue, we expect the angle to be between 240° to 360°

Code: RBG to HSV

Here's an implementation of RGB to HSV using rust:

pub fn rgb_to_hsv(r: u8, g: u8, b: u8) -> (f32, f32, f32) {
    let r = r as f32 / 255.0;
    let g = g as f32 / 255.0;
    let b = b as f32 / 255.0;

    let max = r.max(g).max(b);
    let min = r.min(g).min(b);
    let delta = max - min;

    let h = if delta == 0.0 {
        0.0
    } else if max == r {
        60.0 * (((g - b) / delta) % 6.0)
    } else if max == g {
        60.0 * (((b - r) / delta) + 2.0)
    } else {
        60.0 * (((r - g) / delta) + 4.0)
    };

    let h = if h < 0.0 { h + 360.0 } else { h };
    let s = if max == 0.0 { 0.0 } else { delta / max };
    let v = max;

    (h, s, v)
}

Code on github.

Next time...

In my next post, I'll walk through how to adjust the "saturation" of an image, which is easy if you already have the HSV representation of the image.

So you've written a Rust CLI with Clap and you want to update your README.md with details on how to use it. Well, ConnorGray has written a library that does just that:

GitHub - ConnorGray/clap-markdown: Autogenerate Markdown documentation for clap command-line tools

Autogenerate Markdown documentation for clap command-line tools - ConnorGray/clap-markdown

GitHubConnorGray

Problem: clap-markdown generates markdown just fine, but we want to add the output to our README.md without overwriting the entire contents of the file..

Solution: use hidden comments in the README as a placemarker.

1. Add something like the following to your README.md file:

<!-- start: CLI USAGE -->

<!-- end: CLI USAGE -->

2. Add a hidden command to your CLI as suggested by clap-markdown here, which should call a function that looks something like:

pub fn add_cli_cmd_to_readme() -> Result<()> {
    let md = clap_markdown::help_markdown::<Cli>();

    // Read the README.md file
    let mut content = std::fs::read_to_string("README.md")?;

    // Find the start and end markers
    let start = "<!-- start: CLI USAGE -->";
    let end = "<!-- end: CLI USAGE -->";

    // Replace content between markers
    let start_idx = content
        .find(start)
        .ok_or_else(|| anyhow::anyhow!("Could not find start marker"))?;
    let end_idx = content
        .find(end)
        .ok_or_else(|| anyhow::anyhow!("Could not find end marker"))?;

    content.replace_range((start_idx + start.len())..end_idx, &format!("\n\n{}\n", md));

    // Write back to README.md
    std::fs::write("README.md", content)?;

    println!("Markdown help written to README.md");

    Ok(())
}

This function will add the output of clap_markdown your between the place markers in your README.md.

Example

Here's a repo of mine using it: https://github.com/nbw/foto

I run cargo run – cli-readme to generate a new README.md with updated docs.

This is mostly a PSA because things are much easier than they once were before.

1. ❌ ARCH is hard to install and configure! WRONG – Arch is no longer hard to install. There's a nice install wizard that you can now use: Run archinstall when you're installing the OS.
   1. You can install Hyprland as part of the installer (easy!)
   2. to log into Hyprland, you need to start in TTY mode (ctrl + alt + F4) if you've configured a UI login (maybe you installed Plasma too like I did)
   3. FYI: I installed Arch by putting the disk image on a USB stick and loading it via the bootloader
2. ❌ HYPERLAND is hard to install configure: WRONG – if you want a nice setup to try Hyprland already configured then install the [Hyde project](https://github.com/HyDE-Project/HyDE)
   1. once you've installed Hyde, CMD + / shows you shortcuts.
   2. You can configure hotkeys in ~/.config/hypr/keybindings.conf
   3. run hydectl reload to refresh stuff if needed
   4. there's also Archcraft Hyprland that is worth looking at if you don't like Hyde

Here's a good install guide for Arch:

I started my Linux journey on a cheap ThinkPad X1 Carbon Gen 7 and I opted for NixOS as my Linux distro. It's been great, but to spice things up I also tried Hyprland.

Hyprland is a window manager that automatically organizes new windows for you. At the end of it, you basically have a no-mouse setup– or at least you're not dragging around windows. There are other alternatives (like Sway) out there and they all run a bit differently. I'm not an expert on how Hyprland works (and honestly it's not that important), but there are many people out there who've already written articles on the topic.

If you search "hyprland rice" on Youtube, you'll get endless cool setups.

Sidenote: Hyprland has some problematic history

The creator of Hyprland, Vaxxry, has been banned from a number of Linux communities. I leave it to read to search why, but it's not great.

I willingly tried Hyprland knowing a bit about the drama, but that's not an endorsement of the creator.

My Setup

Hyprland looks cool. That is maybe the one great thing about it. It looks and feels super minimalist.

Hyprland is hard, but cool

Part of me wanted to believe I could make it my daily driver, but the learning curve and required setup is a lot to take on (you setup basically everything). For now, I'm pausing on Hyprland 🛑, but maybe I'll revisit it once I'm ready again. I still have my configs, everything is NixOS based, so I can rebuild my existing setup in a single command.

Here are some of the things you have to setup that you'd otherwise get for free with other distros:

• a task bar
• volume control, brightness control
• search (programs, files, etc.)
• lock screen
• network setup
• file viewer
• power on/off
• auto-sleep the computer
• many other things, but basically everything

The other upside/downside of Hyprland is that it's basically runs on hotkeys. You set those hotkeys so that's nice, but nevertheless you have to remember them. If you step away from your Hyprland setup for a bit, it can feel pretty alien when you come back.

Getting Started

There are a number of tutorials out there, but this is the one that got me started:

For my navigation bar, I ended up finding someone else's implementation online then grabbing what I wanted from it:

• Github: https://github.com/SolDoesTech/HyprV4

Unfortunately I spent countless hours watching videos, reading blogs, etc. to figure out a working setup. It just takes time and I can't remember all the resources I used.

I bought a used Thinkpad X1 Carbon Gen 7 laptop to try Linux and find out if it's right for me.

At the time of writing I'm about a month or more into it.

Why Linux?

For a long time I've been a Mac user. For many reasons, it's been a great choice for me as a developer, as someone who makes music, etc.. I still think Mac is a great option, but I've also always wanted to explore Linux.

I think it started off as wanting to understand computers more, but that wasn't really enough. I hardly ever actually do something because it might be good for me. Certainly not if it requires a ton of effort.

For a while now I've been wanting to decouple my dependency from Apple. My experience being a developer with Mac is to keep installing and adding tools until the thing you're working on just works without cleaning up any messes you made a long the way. What I'm left with is a computer that has so many things installed on it that I can't keep track of it all anymore. It just becomes bloated until I either reset my computer or buy a new one.

Also there are some tools that I want to try that work better (or only work) with Linux. Tools like Firecracker Micro VMs. The developer experience overall just seems to work better on Linux (or matches Mac for the most part).

Ultimately, I want to have more control over what my computer is doing. I want the leanest setup for my needs or at least some better record keeping of what tools I've installed.

I can say already that keeping a lean and organized setup has been empowering.

This isn't the first time I've tried to switch

I actually tried switching to Linux last year when I build a desktop computer for the first time (dual boot Linux and Windows). I started with Manjaro, briefly tried Ubuntu, considered Arch, then ended up on Fedora.

For games (Apex, etc) the Linux setup was great. I rarely had any issues, but in the end my Window was just easier when I wanted to use bluetooth, use an Xbox controller, and use some software that I couldn't get on Linux (I'm looking at you Adobe). So although I have a working Linux desktop, I mostly boot it in Windows these days (sorry!).

For work, I'm still on a Mac

I can't see this changing any time soon. Although my work would permit me to use a Linux setup, I'd have to purchase a computer on my own dime since I have a working laptop already. My M2 Macbook Air works great for work, but if I had to reset it to factory settings then I think it would take me weeks to get back to where I am now. It's one of those if it ain't broke don't fix it situations.

Why not Asahi Linux then?

The Asahi Linux project is creating compatibility with Linux and ARM based Macs. It's a really cool project and I've read many posts of it working great. I just feel that I want to get away from Mac hardware entirely and have a clean break without the option to just switch back to MacOS.

And so..

I hope to post updates of my Linux journey.

This is part 3 in a series about self hosting a Ghost blog on Fly.io. It assumes you have a running Ghost app on Fly (either using SQLite or MySQL).

In the first two posts we covered:

1. Setting up a Ghost blog using SQLite
2. Setting up a Ghost blog using MySQL

Now we'll move onto saving assets (in particular photos that you upload to your blog posts) in a S3 Object Storage bucket.

This is what we're aiming for:

Tigris is awesome

Tigris Global Object Store is a s3 compliant storage system built on Fly's infrastructure. We'll be connecting it to our Ghost Blog. For more details:

Tigris Global Object Storage

Documentation and guides from the team at Fly.io.

Fly

Step 1: Create a Dockerfile

If you've been following the guides up until this point then in your fly.toml file you might have the line:

# fly.toml

# erase this!
[build]
  image = 'ghost:5.81.0'

But in addition to our Ghost image, we also need an Ghost s3 storage library. So, remove the image line from the fly.toml and create a Dockerfile that looks like

FROM ghost:5.81.0-alpine
WORKDIR /var/lib/ghost
RUN npm install --prefix /tmp/ghos3 ghos3 && \
  cp -r /tmp/ghos3/node_modules/ghos3 current/core/server/adapters/storage/s3 && \
  rm -r /tmp/ghos3

RUN npm install ghos3 && npm install aws-sdk

This Dockerfile was written by underlost here: https://github.com/underlost/flyio-ghost-s3

I've modified it to use ghos3 which is a recent rewrite of ghost-storage-adapter-s3.

Step 2: Create a Tigris Object Storage Bucket

You can basically follow the guide for Tigris, but the short version is:

fly storage create <my_bucket_name> --public

You'll get some credentials that you'll want to keep for later:

BUCKET_NAME: my_bucket_name
AWS_ENDPOINT_URL_S3: https://fly.storage.tigris.dev
AWS_ACCESS_KEY_ID: tid_xxxxxx
AWS_SECRET_ACCESS_KEY: tsec_xxxxxx

Step 3: Modify fly.toml and set secrets

Add the following to you fly.toml under [env]

# fly.toml
# don't forget to replace "my_bucket_name" with your own name

[env]
  ##### Tigris S3
  storage__active = "s3"
  # storage__s3__accessKeyId = "" # set as secret
  # storage__s3__secretAccessKey = "" # set as secret
  storage__s3__region = "auto"
  storage__s3__bucket = "my_bucket_name"
  storage__s3__assetHost = "https://fly.storage.tigris.dev/my_bucket_name"
  storage__s3__endpoint = "https://fly.storage.tigris.dev"

• region is auto
• the asset host (storage__s3__assetHost) needs the bucket name in the path
• for uploading (storage__s3__endpoint) should omit the bucket name

Next, set secrets for your app using the credentials from when you made the bucket:

fly secrets set --stage storage__s3__accessKeyId=tid_xxxx storage__s3__secretAccessKey=tsec_xxx

Step 4: Deploy and check that it works:

Run fly deploy to deploy your app.

Then create a draft blog post and try uploading an image.

You can see the image in your bucket by running the following:

flyctl storage dashboard <bucket_name>

This should open up Tigris' dashboard and you can browse the files in your bucket. It's neato burrito.

Final Example:

Putting it all together with MySQL and Tigris Object Storage your fly.toml might look like:

# fly.toml app configuration file generated for nathan-ghost-blog on 2024-07-13T22:34:38+09:00
#
# See https://fly.io/docs/reference/configuration/ for information about how to use this file.
#

app = 'my-ghost-blog'
primary_region = 'sea'

[env]
  ##### MYSQL Database
  database__client = 'mysql'
  # database__connection__user = '' # set as secret
  # database__connection__password = '' # set as secret
  database__connection__host = 'my-blog-db.internal'
  database__connection__port = '3306'
  database__connection__database = 'blog_db'
  database__connection__useSSL = 'false'
  database__useSSL = 'false'
  ##### Tigris S3
  storage__active = "s3"
  # storage__s3__accessKeyId = "" # set as secret
  # storage__s3__secretAccessKey = "" # set as secret
  storage__s3__region = "auto"
  storage__s3__bucket = "my-blog-storage"
  storage__s3__assetHost = "https://fly.storage.tigris.dev/my-blog-storage"
  storage__s3__endpoint = "https://fly.storage.tigris.dev"
  url = 'https://my-ghost-blog.fly.dev'

[http_service]
  internal_port = 2368
  force_https = true
  auto_start_machines = true
  min_machines_running = 0
  processes = ['app']

[[vm]]
  memory = '1gb'
  cpu_kind = 'shared'
  cpus = 1

This part 2 in a series about using Ghost on Fly.io. In part 1, we setup a Ghost blog with SQLite as the database. In this post we'll be setting up a MySQL database and configuring our Ghost app to use it.

By the end we'll have a system that looks like:

Step 1: Create a MySQL database

The details on how to create a MySQL database are here: https://fly.io/docs/app-guides/mysql-on-fly/

There are some things you should keep in mind:

• The MySQL database will run on a single VM. If that VM crashes then you'll have to start it again.
• This is NOT managed MySQL. This is a self-hosted MySQL image on a VM. If you need something resilient, then there are plenty of services out there.

Before configuring Ghost, verify that your MySQL database works

The way I do that is to ssh into the machine running the MySQL image, logging into the database and confirming it works:

# SSH into the app
fly ssh console -a <mysql app name>

# From inside the vm run:
mysql <my_database_name> -u root -p
Enter password:

# use the password you set for MYSQL_ROOT_PASSWORD

# run a command like "SHOW DATABASES" just to see that things work
mysql> SHOW DATABASES;

Step 2: Configure Ghost to use MySQL

The next steps are to update you apps fly.toml and set some secrets.

Update the fly.toml with some Ghost config

In the last post we configured the fly.toml to use a SQLite database. We'll modify the env database bit to look like the following:

# fly.toml

app = <ghost app name>
primary_region = 'sea'

[env]
  ##### MYSQL Database
  database__client = 'mysql'
  # database__connection__user = '' # set as secret
  # database__connection__password = '' # set as secret
  database__connection__host = '<mysql app name>.internal'
  database__connection__port = '3306'
  database__connection__database = '<database name>'
  database__connection__useSSL = 'false'
  database__useSSL = 'false'

...

Set some secrets:

Then we need to set a few secrets on our Ghost app.

fly secrets set --stage database__connection__user=root database__connection__password=[[MYSQL_ROOT_PASSWORD]] -a <ghost app name>

This will set secrets on your app for the next deploy. I'm using the root user and the root password (that's what worked for me).

Final Example:

So for example, let's say I created an app called my-ghost-blog-db and I created a database in it called my_db . Then my fly.toml might look like:

# fly.toml

app = 'my-ghost-blog'
primary_region = 'sea'

[build]
  image = 'ghost:5.81.0'

[env]
  ##### MYSQL Database
  database__client = 'mysql'
  # database__connection__user = '' # set as secret
  # database__connection__password = '' # set as secret
  database__connection__host = 'my-ghost-blog-db.internal'
  database__connection__port = '3306'
  database__connection__database = 'my_db'
  database__connection__useSSL = 'false'
  database__useSSL = 'false'
  url = 'https://my-ghost-blog.fly.dev'

[http_service]
  internal_port = 2368
  force_https = true
  auto_start_machines = true
  min_machines_running = 0
  processes = ['app']

[[vm]]
  memory = '1gb'
  cpu_kind = 'shared'
  cpus = 1

And I'd run something like:

fly secrets set --stage database__connection__user=root database__connection__password=mysecurepassword1234 -a my-ghost-blog

Deploy and check that it works

Run fly deploy for your Ghost app and run fly logs in a separate app to check that it's connecting to the database properly.
